Korg OT-120 Orchestral Tuner
Tune wind and string instruments in a flash with the OT-120, a needle-type meter with a wide range and versatile functionality.
- Chromatic tuner with a wide detection range that supports the instruments used in an orchestra or brass band.
- Dual display provides both a needle-type meter and an LCD for excellent visibility.
- Korg's proprietary Sound Back mode* plays a reference pitch for the note that's closest to the input pitch. The meter indicates the discrepancy between the input and the correct pitch. (When using the separately sold CM-100.)
- Multi Temperament supports historical tuning systems.
- Transpose mode is convenient for wind instruments.
- Choose from three levels of needle response speed.
- Both auto and manual tuning modes are provided.
- Reference tone generation in a five octave range.
- Broad range of calibration adjustment (349 Hz - 499 Hz).
- Built-in mic supports acoustic instruments.
- Energy-saving design for long battery life (approximately 100 hours or greater).
- Suede-tone soft case included.
Vertical-design and superior visibility
The OT-120 is a chromatic tuner intended for the orchestra, packaging high performance and sophisticated functionality in a vertical design that's easy to hold and operate. It features a dual-display, an easy-to-see needle-type indicator and a backlit LCD screen that shows the battery level, sound output level, calibration, key and note name. Additional design features include a large dial that makes it easy to select the desired mode, finger-friendly buttons and a rear-mounted stand that lets the unit stand by itself. A sophisticated silver aluminum panel contributes to its sleek, new look.
Accurately tune orchestral instruments over a wide range
Since Korg developed the world's first meter-type tuner in 1975, the accuracy of their tuners has made them the choice of artists in all styles of music. With its wide range extending from A0 to C8, the OT-120 lets you quickly tune any type of brass band or orchestral instrument – wind, string or keyboard. The OT-120 also provides a wide range of calibration to support concert pitches in a range of A4=349-499 Hz (1 Hz steps).
Smooth and high-precision tuning you expect from a needle-type meter
The OT-120 uses a high-precision needle-type meter to accurately indicate any pitch discrepancy. The speed at which the needle responds to the input can be changed over a range of three steps; you can choose rapid or slow needle movement to match your tuning preference.
You can also choose from two tuning modes; Auto mode, which automatically detects the pitch of a single note you play on the input instrument, or Manual mode, which lets you specify the desired note name. In Manual mode the needle movement is shown in a range of ±500 cents, letting you view the tuning discrepancy over a wide range. In addition to the excellent visibility unique to a needle-type meter, the LEDs located below the meter also indicate pitch deviation or a perfect match, making precise tuning easy even in dim locations.
Korg's proprietary Sound Back mode provides a reference tone that's ideal for tuning wind or string instruments, or for lessons
The OT-120 can produce a reference tone in a five-octave range extending from C2 (65.41 Hz) to C7 (2093 Hz). Two or more musicians can simultaneously listen to the reference tone while tuning. You can switch the output level in two stages. The large speaker opening allows high volume, and the speaker opening is not obstructed even when using the stand, ensuring that the reference tone will be easily audible.
The OT-120 also provides Korg's proprietary Sound Back mode. This mode lets you connect an optional CM-100 contact mic to the input jack, and automatically make the OT-120's speaker produce a reference tone for the note that is closest to the input pitch you play on your instrument. The meter will also indicate the input pitch, letting you tune using your eyes as well as your ears for greater accuracy – and also providing a great way to train your sense of pitch. Since a mic is built in, the OT-120 can easily detect the pitch of any acoustic instrument.
Broad support for transposing instruments and historical temperaments
So that you can conveniently tune any wind instrument, twelve types of transposing keys are provided including both sharps and flats. The Multi Temperament function provides eight presets that cover the most popular historical temperaments often used with period instruments. These are also ideal for checking unique temperaments used in classical music.
Energy-saving design for long battery life
The OT-120 is designed for an extended battery life of greater than 100 hours when running on two AAA batteries. It can also be used with an AC adaptor (separately sold option).
Soft case included
A convenient, suede-tone soft case is included.
- Analogue needle
- Illuminated display
- Tuning range: A0 - C8
- Reference tones: C2 - C7
- Calibration range: A=349Hz - 499Hz in 1 Hz steps
- Detection tolerance: +/-1 cent
- Sound tolerance: +/-1.5 cents
- Scales: Equal temperament; Pythagorean; Mean tone Eb/D#; Werckmeister III; Kirnberger III; Kellner; Vallotti; Young
- Power saving function
- Input jack: 1/4" mono
- Output jack: 1/4" mono
- Power supply: 2 x AAA batteries (included) or DC in
- Battery life: Approx 100 hours (alkaline batteries, meter input with continuous input)
- Approximate dimensions: 74 mm x 120 mm x 36 mm
- Approximate weight: 193 g (including batteries)
